Facilities

WORKSHOP

A.K.K. Engineering workshop is located in Zone 12B, Kampung Pasir Gudang Baru, State of Johor.

It is built on a corner lot land of 2.5 acres.

Our workshop consists of three blocks of buildings with total covered area of 62000 sq. ft. A two storey office block is in the same location which serve as headquarter of A.K.K. Engineering and its subsidiaries.

Our workshop is fully equipped with various fabrication machineries and tools to support our production.

workshop-1
akk-fabrication-workshop-image-block-c
AREA
Land : 10000m²
Fab Space : 6000m²
ELECTRICAL
CURRENT

500Amp
OVER HEAD
CRANE

5 T/10T
FACTORY MAIN
ENTRANCE

9m
MAXIMUM FABRICATION HEIGHT IN FACTORY
10m
Item Overhead Crane
Fabrication Workshop BAY1 & BAY2 24m x 72m  3 units
Fabrication Workshop BAY3 28m x 80m   2 units
overhead-crane-5t

Overhead Crane 5T

overhead-crane-10t-2

Overhead Crane 10T

overhead-crane-10t

Overhead Crane 10T

Item Qty
Overhead Crane 5T 2 units
Overhead Crane 10T 3 units
kaltenbach-cnc-beam-driller

CNC Beam Drilling Machine

  • Model : KALTENBACH KDXS 1015
  • Max. Dimension : 1000mm (W) x 450mm (H)
  • Drill Diameter : 8-40mm
  • Features : 4 side contour marking, auto tool-changer
kaltenbach-cnc-beam-drilling-machine

CNC Bandsaw Machine

  • Model : KALTENBACH KBS 1010 DG
  • Max. Dimension : 1010mm (W) x 500mm (H)
  • Swivel Angle: -45o to +30o
  • Cutting Speed : 15-120m/min
  • Saw Band Feed : 0-400mm/min
cnc-plasma-and-flame-cutter

 CNC Plasma & Flame Cutter

  • Model : BODA 3500 x 10000
  • Effective Working Area : 2.5m (W) x 6.5m (L)
  • Plasma Model : Thermal Dynamic Autocut 200
  • Max. Cutting Thickness (Plasma) : 50mm
  • Max. Cutting Thickness (Flame) : 100mm
auto-shot-blasting-machine-akk

Shot Blasting Machine

  • Model : AKK Design H1220
  • Max. Piece : 1.2m wide x 2m high x 15m long
  • Monthly Output : 2000 to 3000 tons /month
  • Wheeler : 11kW x 10 units
  • Surface Finishing : Up to Sa3.0
  • Surface Roughness :  Ra30-75μm
  • Dust Removal Efficiency :  ≤50mg/m3
blasting-chamber

Blasting Chamber

  • Dimension : 5m (W) x 20m (L) x 5m (H)
cnc-driller

CNC Plate Drilling Machine

  • Model : Proarc Drill+ 1020
  • Capacity : 50mm diameter x 100mm thick
  • Table Dimension : 1000mm x 2000mm
faccin-plate-roller

Plate Roller

  • Model : FACCIN 3HEP-S75
  • Max. Plate Width : 3.05m
  • Max. Plate Thickness : 26mm @ 1900mm diameter
  • Top Roller Dia. : 380mm
  • Power : 30hp
double-mitter-bandsaw

Double Mitter Bandsaw

  • Model : Bigstone CF-1000DMS
  • Capacity : 1000mm (W) x 650mm (H)
  • Power : 7.5kW
hydraulic-ironworker

Hydraulic Ironworker

  • Model : Sunrise IW80SD
  • Capacity : 80 tons
welding-set

Auto Tank Welder

Auto Tank Welder

  • Model : Hua Heng
  • Max. Vertical Movement : 4m
  • Max. Horizontal Movement : 4m
  • Welding Set : Lincoln SAW 1000A
fcaw-wedling-set

FCAW Welding Set
500 A ( 20 sets)

smaw-welding-set

SMAW Welding Set
300 – 400 A

gtaw-welding-set

GTAW Welding Set
200 – 400 A

lincoln-powerplus-ii-650-gouging-machine

Lincoln PowerPlus II 650
Gouging Machine

auto-oxy-cutter

Auto Oxy Cutter

oven

Baking & Holding Oven

weld-edge-beveller

Weld Edge Beveller

grinder-7in

Grinder 7 inch

magnetic-drill

Magnetic Drill

70-tons-mobile-crane-kato

70 T Mobile Crane 1

50-ton-mobile-crane

 50 T Mobile Crane 2

mobile-crane-1

 25 T Mobile Crane 3

mobile-crane-4

25 T Mobile Crane 4

excavator-1

Excavator 1

excavator-2

 Excavator 2

backhoe

Backhoe

compacter

Vibratory Compactor
10 tons

boom-lift

Sky Lift
18 M

piling-frame

 Hydraulic Piling Machine 2.5T

lorry

30 Footer Cargo Lorry

pickup

Toyota/Isuzu Pickup

forklift-7mt

Forklift 7MT

45-footer-low-loader-prime-mover2

45 footer Low Loader

tools

A.K.K. Engineering is also fully equipped with all the vital and essential calibrated precision measurement tools and instruments to facilitate proper quality inspection and check during fabrication works.

Some of these high precision tools are as follows:

  • DFT Thickness Gage
  • Surface Profile Gage
  • Ultrasonic Thickness Gage
  • Hygrometer
  • Digital Linear Measurement
  • Digital Angle Measurement
  • AC/DC Clamp Meter
  • Infrared Thermometer
  • Micrometer
  • Digital Vernier Caliper
  • Temperature Gage
  • Optical Leveller
  • X-Ray Film Viewer and Densitometer
  • Laser Alignment Kit
  • Hydraulic Test Kit
  • Flexible Tape
  • Gas Tester
diesel-engine-welding-set

 Diesel Engine Welding Set

diesel-genset-150kva

 Diesel Genset 150kVA

container

20’/40′ Container
